Universal Audio 1176 LN

Universal Audio 1176 LN

The Universal Audio 1176 LN is based on the E&F versions of the black-faced original, with the sole addition of XLR I/O as well as the original screw-in terminals.

This Universal Audio Classic version of the 1176LN captures all the nuance of the original through obsessive attention to detail and delivers that trademark sound, to make your vocals sit, king on guitar, magic on bass and stunning on drums.

Evolved from 175 and 176 Designs

The Universal Audio 1176 LN design is based upon the original Universal Audio 1176LN, designed by Bill Putnam, which was a major breakthrough in limiter technology, the first true peak limiter with all transistor circuitry offering superior performance and a signature sound.

Evolved from the popular Universal Audio 175 and 176 vacuum tube limiters, the 1176LN retained the proven qualities of these industry leaders and set the standard for all limiters to follow.

Modern Classic

Today, the 1176LN is new again. While it certainly would have been possible and much simpler to modernize and "improve" the 1176LN, every effort was made to remain faithful to Putnam's design and intentions. Carefully trained staff hand-wire and test each unit until it meets Universal Audio's uncompromising standards.

With Ultra-fast attack times from 20 microseconds to 800 microseconds and ddjustable release time 50 milliseconds to 1.1 second and still featurign the Custom-built Putnam-designed output transformer - The Universal Audio 1176 LN Solid State Limiting Amplifier - Legendary, high-end, compressor/limiter used for vocal, bass and instrument tracking across the world.

Specifications

    •    Input Impedance 600 ohms, bridges-T control (floating)
    •    Output Load Impedance 600 ohms, floating, damping factor 20
    •    External Connections Jones Barrier terminals and XLR connectors
    •    Frequency Response ± 1 dB 20 Hz to 20kHz
    •    Gain 50 dB
    •    Distortion Less than 0.5% total harmonic distortion from 50 Hz to 15 kHz with limiting
    •    Signal to Noise Ratio Greater than 70 dB at +10 dBm
    •    Attack Time 20 microseconds to 800 microseconds
    •    Release Time 50 milliseconds to 1.1 seconds
    •    Stereo Interconnection via 1176 SA Network accessory
    •    Meter dB gain reduction and dB output
    •    Power Requirements 120/240 V
